3onedata IMC101GT 2-Port Full Gigabit Industrial Media Converter
3onedata IMC101GT 2-Port Full Gigabit Industrial Media Converter
Lead Time
Product Description
3onedata IMC101GT 2-Port Full Gigabit Industrial Media Converter is designed for connecting equipment through the network functions listed below. It suits installers matching existing equipment to the ports, protocols and physical installation this model supports. Fiber Interface support is listed as 1 × 1000Base-X SFP slot. It accepts 12-48V DC terminal block at the specified input. IP40 metal enclosure is specified for the housing. When choosing this industrial networking device, start with the documented configuration.
Check the communication requirements at both ends of the connection. Port format alone does not establish protocol compatibility, and the stated power and mounting arrangement also need to suit the installation. The Mounting specification is DIN rail. The dimensions figure is 35 × 110 × 95mm. The Device Type specification is 2-port full-Gigabit unmanaged industrial media converter. The Copper Port specification is 1 × 10/100/1000Base-T(X) RJ45. The Standards specification is IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x.
Applications
Product Specifications
| Brand | 3onedata |
|---|---|
| Model | IMC101GT |
| Device Type | 2-port full-Gigabit unmanaged industrial media converter |
| Copper Port | 1 × 10/100/1000Base-T(X) RJ45 |
| Fiber Interface | 1 × 1000Base-X SFP slot |
| Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x |
| Transmission | Store and forward |
| Forwarding Rate | 148,810pps at 100M; 1,488,100pps at 1000M |
| MAC Address Table | 1K |
| Packet Buffer | 1Mbit |
| Backplane Bandwidth | 12Gbps |
| Link Monitoring | LFP supported |
| Power Input | 12-48V DC terminal block |
| Protection | Non-polarity and reverse-polarity protection |
| Housing | IP40 metal enclosure |
| Mounting | DIN rail |
| Dimensions | 35 × 110 × 95mm |
| Weight | ≤350g |
| Operating Temperature | -40°C to 75°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5-95%, non-condensing |
| Certification | CE, FCC, RoHS |
Product Features
- Gigabit fiber extension:Converts between copper Gigabit Ethernet and a 1000Base-X SFP fiber link.
- Automatic copper interface:Available functions include 10/100/1000Mbps auto-negotiation, flow control and MDI/MDI-X.
- Link monitoring:LFP propagates fiber or copper link faults for faster troubleshooting.
- Industrial power:Accepts 12-48V DC through a terminal block with reverse-polarity protection.
- Harsh-environment design:Supported by Fanless IP40 metal housing: wide operating temperatures.
- Compact installation:DIN-rail format fits industrial control cabinets and edge-network panels.
Package Includes
- 1 × 3onedata IMC101GT industrial media converter
- DIN-rail mounting hardware
- Quick installation documentation
- Datasheet access
