Product Description
The Avyanna Tech AT-7021 is a Linux-based energy-monitoring edge gateway with two isolated RS-485 interfaces plus Wi-Fi and Bluetooth. It combines Modbus RTU device collection with network and wireless interfaces for industrial energy monitoring.
Key functions include linux-based industrial energy-monitoring gateway; 2 isolated RS-485 serial ports; wi-Fi and Bluetooth connectivity. Check the product specifications for supported electrical, interface, installation and operating requirements before selecting equipment for your system.
Applications
Product Specifications
| General | |
|---|---|
| Brand | Avyanna Tech |
| Model | AT-7021 |
| Product Type | Linux-Based Edge IoT Energy Monitoring Gateway |
| I/O & Signal Performance | |
| RS485 Termination | 120 ohm |
| Connectivity & Configuration | |
| SoC Family | 32-bit ARM Cortex-based processor |
| RAM | 256 MB DDR3L |
| eMMC NAND Flash | 512 MB |
| Serial Interface | 2 × isolated RS485 |
| Modbus Support | Modbus RTU |
| Default Baud Rate | 9600, custom configurable |
| Parity | None, Even, Odd |
| Data Bits | 8 / 9 bit including parity |
| Stop Bits | 1, 2 |
| Ethernet | 1 × 10/100 Mbit/s RJ45 |
| Ethernet Timing | IEEE 1588 compliant timer |
| Wireless Connectivity | Wi-Fi & Bluetooth |
| Power & Protection | |
| Operating Voltage | 6V to 27V |
| Power Consumption | 1.68W @24V, 1.44W @12V |
| Galvanic Isolation | 2.5 kV |
| Compliance & Origin | |
| Country of Origin | India |
| Other Specifications | |
| CPU | 1 × ARM Cortex-A7, 900 MHz |
| RTC | Built-in |
| RS485 Signal | 2-wire D+, D-, GND |
| RS485 Direction Control | ADDC (Automatic Data Direction Control) |
| USB | 1 × USB 2.0 Host, 1 × USB Host/Client (Micro AB) |
| USB Speed | 480 Mbit/s |
| SD Card | 1 × Micro SDHC; SD-XC capacity up to 2 TByte |
| Remote Connectivity | GSM and Ethernet |
Product Features
- Supported by Linux-based edge IoT architecture: local energy-data acquisition and industrial gateway functions.
- Dual isolated RS485 ports provide consistent Modbus RTU communication with industrial devices and energy meters.
- 2.5 kV galvanic isolation can help protect serial communication in electrically noisy industrial environments.
- Ethernet, GSM, Wi-Fi and Bluetooth connectivity provide flexible options for local and remote communications.
- Supported by On-board Micro SDHC storage: continuous local data logging, with SD-XC capacity up to 2 TByte.
- Provided by Built-in RTC: accurate event timestamping, while USB Host and USB OTG interfaces support service and expansion requirements.
Package Includes
- 1 × Avyanna Tech AT-7021 Wireless Linux Edge Energy Gateway
Power supplies, cables and optional accessories are included only if specified in the order.
