Waveshare ESP32-C6 1.9 Inch 170x320 Display Development Board Without Touch
Waveshare ESP32-C6 1.9 Inch 170x320 Display Development Board Without Touch
Low Stock, 1 left
Product Description
The Waveshare ESP32-C6 1.9 Inch 170×320 Display Development Board Without Touch is a compact Wi-Fi 6 and Bluetooth LE development platform with integrated color LCD. It includes motion sensing, microSD, USB-C and battery support for dashboards, portable instruments and connected embedded products that do not require a touch panel.
Applications
Product Specifications
| MCU | ESP32-C6 |
|---|---|
| CPU | RISC-V, up to 160MHz |
| Wireless | Wi-Fi 6, Bluetooth 5 LE/Mesh |
| Display | 1.9 inch LCD |
| Resolution | 170 × 320 |
| Display Controller | ST7789V2 |
| Touch | No touch |
| IMU | QMI8658 6-axis |
| Storage | TF / microSD |
| USB | USB-C |
| Battery Support | Supported |
Product Features
- ESP32-C6 Wireless Platform
Provides modern Wi-Fi 6 and Bluetooth Low Energy connectivity with RISC-V processing. - Integrated Color Display
The 1.9 inch 170×320 panel provides local visualization without requiring a separate display module. - Onboard Motion Sensor
QMI8658 six-axis IMU supports orientation and motion-aware applications. - Portable Expansion
microSD, USB-C and battery support make the board suitable for standalone prototypes.
Package Includes
1 × Waveshare ESP32-C6 1.9 Inch 170x320 Display Development Board Without TouchOther Information
Warranty Information
15 Days Seller Warranty:
This item is covered with a standard warranty of 15 days from the time of delivery against manufacturing defects only. This warranty is given for the benefit of TwoElectrons customers from any kind of manufacturing defects. Replacement will be done against manufacturing defects.
What Voids Warranty:
If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
Shipping & Returns Policy
Shipping Policy:
- Delivery time within metro cities in India is 1-3 days; for other locations, it is 3-7 days. Delivery varies based on location and courier service.
- If the item is out of stock, the estimated delivery time is 7-14 days from order confirmation. Delivery varies based on location and courier service.
Return & Refund Policy:
- Return window: 7 days from receipt unless stated otherwise.
- No refunds or replacements after the return window.
- Returns are accepted only for non-working or damaged products.
- Initiate return requests from here: Return Request or contact us at 09831070550.
- Refunds are processed within 3-4 working days after inspection and approval.
Main Features
- ESP32-C6 RISC-V MCU up to 160MHz
- Wi-Fi 6 and Bluetooth 5 LE/Mesh
- 1.9 inch 170×320 color LCD
- Non-touch display version
- ST7789V2 display controller
- QMI8658 6-axis IMU
- TF/microSD support
- USB-C and lithium-battery support
- Suitable for Arduino and ESP-IDF projects
SKU: 2EMK2023
₹ 1,934.90
