AT-08-19CT - 19" Industrial Full HD LED Display
AT-08-19CT - 19" Industrial Full HD LED Display
Low Stock, 5 left
Product Description
The Avyanna Tech AT-08-19CT is a 19-inch industrial LED touch display designed for industrial HMI, machine monitoring and visualization applications. It combines a 1280 × 1024 LED panel, capacitive multi-touch input, HDMI/DisplayPort/VGA connectivity, VESA mounting, 12VDC operation and an IP65-certified front panel for dependable indoor industrial use.
Product Specifications
| Brand | Avyanna Tech |
|---|---|
| Model | AT-08-19CT |
| Product Type | 19-inch Industrial LED Touch Display |
| Display Type | LED |
| Display Size | 19 inches |
| Maximum Resolution | 1280 × 1024 |
| Contrast Ratio | 1000:1 (Typ.) |
| Maximum Colors | 16.7 million colors |
| Backlight MTBF | 50,000 hours |
| Display Mode | Normally Black |
| Viewing Angle | 170° / 160° |
| Luminance | Minimum 250 cd/m² |
| Touchscreen | Capacitive Touch (USB interface) |
| External I/O | 1 × USB 2.0, 1 × HDMI, 1 × DP, 1 × VGA |
| Power Input | 12VDC |
| Maximum Current | 0.5 A (Typ.) |
| Maximum Power | 15 W |
| Dimensions | 417.36 (W) × 342.41 (H) × 57 (D) mm approx. |
| Weight | Approx. 3 kg in detailed specification table; page 1 overview states approx. 4 kg |
| Mounting | VESA Mount |
| External Finish | Black |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -10°C to 60°C |
| Humidity | 5% to 95% RH, non-condensing @ 40°C |
| Ingress Protection | IP65 – Front panel certified |
| Certification | CE, FCC – Certified |
| Country of Origin | India |
Product Features
- 19-inch LED panel supports 16.7 million colors, normally-black display mode and a 50,000-hour backlight MTBF.
- Capacitive touch interface connects through USB for operator interaction and industrial HMI applications.
- External video interfaces include 1 × HDMI, 1 × DisplayPort and 1 × VGA, along with 1 × USB 2.0.
- Wide 170°/160° viewing angle and minimum 250 cd/m² luminance support visibility across varied industrial installations.
- VESA mounting and black industrial enclosure support panel, machine and equipment integration.
- Front panel is IP65 certified for improved protection against dust and water ingress.
- CE and FCC certifications are stated in the OEM datasheet.
Package Includes
- 1 × AT-08-19CT Industrial Display
- 1 × AC Power Cable, 1 m
- 4 × Mounting Screws
- 1 × User Manual
Other Information
Country of Origin: India
Warranty Information
1 Year Seller Warranty
This item is covered with a standard warranty of 1 year from the time of delivery against manufacturing defects only. This warranty is given for the benefit of TwoElectrons customers from any kind of manufacturing defects. Replacement will be done against manufacturing defects.
What Voids Warranty
If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
Shipping & Returns Policy
Shipping Policy:
- Delivery time within metro cities in India is 1-3 days; for other locations, it is 3-7 days. Delivery varies based on location and courier service.
- If the item is out of stock, the estimated delivery time is 7-14 days from order confirmation. Delivery varies based on location and courier service.
Return & Refund Policy:
- Return window: 7 days from receipt unless stated otherwise.
- No refunds or replacements after the return window.
- Returns are accepted only for non-working or damaged products.
- Initiate return requests from here: Return Request or contact us at 09831070550.
- Refunds are processed within 3-4 working days after inspection and approval.
Main Features
- 19-inch industrial LED display with 1280 × 1024 resolution and 1000:1 contrast ratio
- Capacitive multi-touch input with USB interface
- Minimum 250 cd/m² brightness for industrial viewing environments
- HDMI, DisplayPort, VGA and USB 2.0 external interfaces
- VESA mounting with IP65-certified front panel
- 12VDC input with maximum power consumption of 15W
SKU: 2EEN20199
₹ 46,610.00
