AT-24033 – 8 Digital Relay Output Module with Modbus TCP
Low Stock, 1 left
Product Description
The Avyanna Tech AT-24033 is an eight-channel relay-output module for Ethernet-based industrial switching. It allows Modbus TCP control systems to operate connected relay loads through its eight output channels.
Key functions include eight digital relay output channels; modbus TCP over Ethernet; rJ-45 10/100 Mbps network interface. Check the product specifications for supported electrical, interface, installation and operating requirements before selecting equipment for your system.
Product Specifications
| General | |
|---|---|
| Manufacturer | Avyanna Tech |
| Model / MPN | AT-24033 |
| Product Type | 8-Channel Digital Relay Output Module |
| I/O & Signal Performance | |
| Relay Outputs | 8 channels |
| Relay Contact | 1 Form A (SPDT) |
| Contact Material | AgSnO₂ / AgNi |
| Contact Rating | 5 A @ 250 VAC / 30 VDC |
| Connectivity & Configuration | |
| Protocol | MODBUS TCP |
| Ethernet Interface | RJ-45 |
| Ethernet Speed | 10/100 Mbps |
| Configuration | Web server & Ethernet Utility |
| Watchdog | 2-second system & communication watchdog |
| Power & Protection | |
| Operating Voltage | 9–36 VDC |
| Power Consumption | IDLE: 1.2 W @ 24V; FULL LOAD: 7.9 W @ 24V |
| Isolation | 1500 VDC |
| Physical & Environmental | |
| Mounting | DIN Rail |
| Compliance & Origin | |
| Certification | RoHS |
Product Features
- 8-Channel Digital Relay Output:Eight relay outputs for industrial automation and remote control applications.
- AC/DC Load Switching:Contact rating up to 5 A @ 250 VAC / 30 VDC.
- Relay Contacts:1 Form A (SPDT) contacts with AgSnO₂ / AgNi contact materials.
- Modbus TCP Ethernet:Industrial Ethernet communication with Modbus TCP support.
- Remote Configuration:Web server and Ethernet Utility for setup and commissioning.
- Watchdog Protection:2-second system and communication watchdog support.
- Isolation:1500 VDC isolation for industrial reliability.
- Wide DC Supply:Operates from 9–36 VDC.
- Industrial Installation:DIN rail mounting for control panels and distributed I/O systems.
Package Includes
- 1 × Avyanna Tech AT-24033 8-Channel Relay Output Module
Power supplies, cables and optional accessories are included only if specified in the order.
Frequently Asked Questions
What is the AT-24033 – 8 Digital Relay Output Module with Modbus TCP used for?
What are its main features?
What are the power or battery requirements?
Which interfaces or communication protocols does it use?
What is included in the package?
Other Information
Warranty Information
1 Year Seller Warranty
This item is covered with a standard warranty of 1 year from the time of delivery against manufacturing defects only. This warranty is given for the benefit of TwoElectrons customers from any kind of manufacturing defects. Replacement will be done against manufacturing defects.
What Voids Warranty
If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
Shipping & Returns Policy
Shipping Policy:
- In-stock items are delivered within 7-10 working days for orders within India. Delivery varies based on location and courier service.
- In-stock items are delivered within up to 20 working days for orders outside India. Delivery varies based on location and courier service.
- If the item is out of stock, you can still place an order. The estimated delivery time will be notified to you by email.
Return & Refund Policy:
- Return window: 7 days from receipt unless stated otherwise.
- No refunds or replacements after the return window.
- Returns are accepted only for non-working or damaged products.
- Initiate return requests from here: Return Request or contact us at 09831070550.
- Refunds are processed within 3-4 working days after inspection and approval.
Main Features
- 8 industrial relay output channels
- Modbus TCP Ethernet protocol
- RJ-45 10/100 Mbps connectivity
- 9–36 VDC operating supply
- DIN-rail industrial installation
