NB-IoT & LTE-M Compact Bluetooth Gateway
Lead Time
Product Description
Pocket-sized BLE gateway with rechargeable battery and global NB-IoT/LTE-M backhaul for portable deployments.
Product Specifications
| Product Specifications | |
|---|---|
| Manufacturer | Lansitec |
| Product family | IoT gateway |
| Dimension | 97*62*7mm |
| Housing Materials | ABS |
| Operating Temperature | -10°C ~ +65°C |
| Storage Temperature | -20°C ~ +80°C |
| Operating Humidity | 5% ~ 95% (non-condensing) |
| Weight | 35g |
| Power | Battery |
| Li-ion rechargeable battery 600mAh | Power Supply Mode |
| 5V/1A | Standby Current |
| 25μA | Max. Current |
| 350mA | Bluetooth Positioning |
| Approx. 2250 times | GNSS |
| Approx. 900 times | Charge Jack |
| Micro USB | Connectivity |
| Protocol | MQTT, HTTP |
| LoRaWAN | Optional |
| LTE-FDD | Band |
| Data Rate (Peak) | LTE-M |
| B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/ B20/B25/B26/B27/B28/B66/B85 | 588 (DL) 1119 (UL) |
| NB-IoT | B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/ B20/B25/B28/B66/B71/B85 |
| Cat NB2: 127 (DL) 158.5 (UL) Cat NB1: Max. 32 (DL) Max. 70 (UL) | Wifi |
| Optional, 2.4GHz, positioning only | N/A |
| SIM Card | Nano and eSIM |
| N/A | Bluetooth |
| Technical reference | Manufacturer product page |
Product Features
- NB-IoT & LTE-M Worldwide
Dual LPWAN radios across 20+ FDD bands for truly global roll-outs. - BLE 5.0 Multi-Protocol
Ingests iBeacon, Eddystone, and private sensor payloads with 3 m indoor accuracy. - Credit-Card Form Factor
97 × 62 × 7 mm, 35 g, easy to slip into vehicles, cabinets, or tool cases. - 10 h On-Board Battery
600 mAh Li-ion keeps reporting when external power is unavailable. - Smart Payload Filter & Compression
Edge processing slashes cellular data fees.
Package Includes
- 1 × NB-IoT & LTE-M Compact Bluetooth Gateway
- Standard accessories for the selected configuration
- Digital product documentation
Other Information
Country of Origin: China
Warranty Information
1 Year Seller Warranty:
This item is covered with a standard warranty of 1 year from the time of delivery against manufacturing defects only. This warranty is given for the benefit of TwoElectrons customers from any kind of manufacturing defects. Replacement will be done against manufacturing defects.
What Voids Warranty:
If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
Shipping & Returns Policy
Shipping Policy:
- Delivery time within metro cities in India is 1-3 days; for other locations, it is 3-7 days. Delivery varies based on location and courier service.
- If the item is out of stock, the estimated delivery time is 7-14 days from order confirmation. Delivery varies based on location and courier service.
Return & Refund Policy:
- Return window: 7 days from receipt unless stated otherwise.
- No refunds or replacements after the return window.
- Returns are accepted only for non-working or damaged products.
- Initiate return requests from here: Return Request or contact us at 09831070550.
- Refunds are processed within 3-4 working days after inspection and approval.
Main Features
- NB-IoT & LTE-M Worldwide
- BLE 5.0 Multi-Protocol
- Credit-Card Form Factor
- 10 h On-Board Battery
- Smart Payload Filter & Compression
