AT-25002 – 7-Channel RTD Module with Modbus TCP
Low Stock, 1 left
Product Description
The Avyanna Tech AT-25002 is a seven-channel RTD temperature-input module using Modbus TCP over Ethernet. It connects Pt100 and Pt1000 resistance temperature detectors for multi-point temperature monitoring in compatible industrial networks.
Key functions include 7 differential RTD input channels; pt100 and Pt1000 RTD sensor support; 2-wire / 3-wire / 4-wire sensor connection. Check the product specifications for supported electrical, interface, installation and operating requirements before selecting equipment for your system.
Applications
Product Specifications
| General | |
|---|---|
| Manufacturer | Avyanna Tech |
| Model | AT-25002 |
| Product Type | 7-Channel RTD Input Module |
| I/O & Signal Performance | |
| RTD Channels | 7 differential |
| RTD Input Type | Pt100 / Pt1000 |
| Accuracy | 0.5°C (0.05% of full scale) max |
| Connectivity & Configuration | |
| Supported Protocol | Modbus TCP |
| Watchdog Timer | System (2 second) & Communication |
| Configuration Tool | Web server & Ethernet Utility |
| Ethernet Protocols | Modbus TCP, TCP/IP, HTTP, DHCP, DNS, UDP, ARP |
| Ethernet Interface | 1 × RJ-45 Female, 10/100 Mbit/s |
| Power & Protection | |
| Operating Voltage | 9–36 VDC |
| Physical & Environmental | |
| Pt100 Temperature Range | -200°C to 850°C typical |
| Pt1000 Temperature Range | -70°C to 550°C typical |
| Mounting | DIN Rail |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | 0°C to 70°C |
| Operating Humidity | 20–95% RH |
| Compliance & Origin | |
| Certification | RoHS |
| Country of Origin | India |
| Other Specifications | |
| Input Connections | 2-wire / 3-wire / 4-wire |
Product Features
- seven differential RTD input channels for industrial temperature acquisition is provided by the unit.
- Available functions include Pt100 and Pt1000 RTD temperature sensors.
- Available functions include 2-wire, 3-wire and 4-wire RTD connections for flexible installation.
- a typical Pt100 measurement range from -200°C to 850°C is provided by the unit.
- a typical Pt1000 measurement range from -70°C to 550°C is provided by the unit.
- Offers a maximum accuracy of 0.5°C (0.05% of full scale).
- Communicates using Modbus TCP over a 10/100 Mbit/s Ethernet interface.
- Available functions include web server and Ethernet Utility configuration with a 2-second system and communication watchdog.
Package Includes
- 1 × Avyanna Tech AT-25002 7-Channel RTD Module with Modbus TCP
Frequently Asked Questions
What is the AT-25002 – 7-Channel RTD Module with Modbus TCP used for?
What are its main features?
What are the power or battery requirements?
Which interfaces or communication protocols does it use?
What is included in the package?
Other Information
Warranty Information
1 Year Seller Warranty
This item is covered with a standard warranty of 1 year from the time of delivery against manufacturing defects only. This warranty is given for the benefit of TwoElectrons customers from any kind of manufacturing defects. Replacement will be done against manufacturing defects.
What Voids Warranty
If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
Shipping & Returns Policy
Shipping Policy:
- In-stock items are delivered within 7-10 working days for orders within India. Delivery varies based on location and courier service.
- In-stock items are delivered within up to 20 working days for orders outside India. Delivery varies based on location and courier service.
- If the item is out of stock, you can still place an order. The estimated delivery time will be notified to you by email.
Return & Refund Policy:
- Return window: 7 days from receipt unless stated otherwise.
- No refunds or replacements after the return window.
- Returns are accepted only for non-working or damaged products.
- Initiate return requests from here: Return Request or contact us at 09831070550.
- Refunds are processed within 3-4 working days after inspection and approval.
Main Features
- 7 differential RTD input channels
- Pt100 / Pt1000 sensor compatibility
- 2-wire / 3-wire / 4-wire sensor inputs
- Modbus TCP over 10/100 Mbps Ethernet
- 9–36 VDC power and DIN-rail mounting
SKU: 2EEN20176
₹ 16,100.00
