EX-301 Wireless Temperature and Vibration Sensor
Low Stock, 5 left
Product Description
LoRaWAN Wireless Temperature and Vibration Sensor
The EX-301 Wireless Vibration and Temperature Monitoring Device, utilizing LoRa technology, is capable of simultaneously measuring and monitoring the vibration and temperature of the target object.
The EX-301 Wireless LoRaWAN Temperature and Vibration Monitoring Unit is a high-performance device that offers simultaneous measurement and monitoring of the vibration and temperature of target objects. Equipped with advanced intelligent analysis algorithms, it not only collects raw acceleration data but also accurately records the time and duration of peak acceleration events.
Designed with low power consumption in mind, the unit can operate reliably for extended periods on battery power, reducing maintenance costs and frequency. Its housing is made of high-strength alloy material with explosion-proof capabilities, making it suitable for harsh industrial environments with high temperatures and intense vibrations.
Widely applicable across industries such as chemical, metallurgical, power generation, and mechanical manufacturing, the monitoring unit is ideal for online monitoring of vibration and surface temperature in critical equipment like pipelines, generators, air compressors, and pumps. With real-time data monitoring and intelligent analysis, EX-301 provides robust support for the health management and predictive maintenance of industrial equipment.
Applications
Product Specifications
| Model | EX-301 |
|---|---|
| Product type | Wireless temperature and vibration sensor |
| Wireless protocol | LoRaWAN Class A |
| Frequency bands | CN470 / EU868 / US915 / AS923 / AU915 MHz |
| Maximum transmit power | 19dBm |
| Maximum receive sensitivity | -141dBm (SF12) |
| Data-transfer rate | 300bps to 5.4Kbps |
| Temperature measurement range | -40°C to 125°C |
| Temperature accuracy | ±0.1°C under stable temperature conditions |
| Velocity measurement range | 0.1 to 199.9mm/s |
| Acceleration measurement range | 0.001 to 156.800m/s² (±16g) |
| Displacement measurement range | 0.01 to 1.99mm/s (source-listed) |
| Measurement accuracy | ±10% at 100Hz |
| Operating temperature | -10°C to +80°C |
| Operating humidity | 10% to 95% |
| Ingress protection | IP67 |
| Mounting type | Bolt / Magnetic |
| Power supply | Built-in 3.6V / 8500mAh battery |
| Battery specification | ER26500 + UPC0920 |
Product Features
- Monitors equipment surface temperature and vibration data simultaneously for online condition monitoring.
- Intelligent analysis captures raw acceleration data and records the time and duration of peak acceleration events.
- Supports CN470, EU868, US915, AS923 and AU915 regional LoRaWAN frequency plans.
- Measures velocity from 0.1 to 199.9mm/s, acceleration from 0.001 to 156.800m/s² (±16g), and source-listed displacement from 0.01 to 1.99mm/s.
- Suitable for predictive maintenance of pipelines, generators, air compressors, pumps and other critical industrial equipment.
- Designed for chemical, metallurgical, power-generation and mechanical-manufacturing environments.
Package Includes
- 1 × EX-301 Wireless Temperature and Vibration Sensor
- 1 × Built-in 3.6V 8500mAh battery
Other Information
Warranty Information
1 Year Seller Warranty
This item is covered with a standard warranty of 1 year from the time of delivery against manufacturing defects only. This warranty is given for the benefit of TwoElectrons customers from any kind of manufacturing defects. Replacement will be done against manufacturing defects.
What Voids Warranty
If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
Shipping & Returns Policy
Shipping Policy:
- Delivery time within metro cities in India is 1-3 days; for other locations, it is 3-7 days. Delivery varies based on location and courier service.
- If the item is out of stock, the estimated delivery time is 7-14 days from order confirmation. Delivery varies based on location and courier service.
Return & Refund Policy:
- Return window: 7 days from receipt unless stated otherwise.
- No refunds or replacements after the return window.
- Returns are accepted only for non-working or damaged products.
- Initiate return requests from here: Return Request or contact us at 09831070550.
- Refunds are processed within 3-4 working days after inspection and approval.
Main Features
- Simultaneous wireless temperature and vibration monitoring
- LoRaWAN Class A communication for long-range industrial connectivity
- Measures vibration velocity, acceleration and displacement
- Records raw acceleration data and peak-event timing and duration
- -40°C to 125°C temperature measurement range
- IP67 high-strength alloy industrial enclosure
- Bolt or magnetic mounting
- Built-in 3.6V 8500mAh battery for low-maintenance operation
