AT-09-BXPC-Orin – AI Inference System Based on NVIDIA® Jetson Orin NX / Orin Nano
AT-09-BXPC-Orin – AI Inference System Based on NVIDIA® Jetson Orin NX / Orin Nano
Low Stock, 1 left
Product Description
AT-09-BXPC-Orin – AI Inference System Based on NVIDIA® Jetson Orin NX / Orin Nano is designed for the applications supported by the specifications below. It suits users selecting this exact part by its documented function, connection and physical format. The dimensions figure is 148 × 120 × 52 mm. The Mounting specification is DIN-rail / VESA (optional). The Wireless Support specification is Wi-Fi / LTE via expansion. When choosing this ai edge box pc / industrial ai controller, start with the documented configuration. Match the part’s stated requirements to the equipment or assembly you already have. The package list establishes what is supplied, while compatibility and operating conditions should be checked separately when planning the complete installation. The Compute Variants specification is Orin NX 16GB / Orin NX 8GB / Orin Nano 8GB / Orin Nano 4GB. The AI Performance specification is 20 / 40 / 70 / 100 TOPS, variant dependent. The OS specification is Linux® Ubuntu 20.04 + JetPack 5.x. The Ethernet specification is 2 × 10/100/1000 Mbps.
Applications
Product Specifications
| Brand | Avyanna Tech |
| Model | AT-09-BXPC-Orin |
| Product Type | AI Edge Box PC / Industrial AI Controller |
| Compute Variants | Orin NX 16GB / Orin NX 8GB / Orin Nano 8GB / Orin Nano 4GB |
| AI Performance | 20 / 40 / 70 / 100 TOPS, variant dependent |
| OS | Linux® Ubuntu 20.04 + JetPack 5.x |
| Ethernet | 2 × 10/100/1000 Mbps |
| USB | 4 × USB 3.0 Type-A; 1 × USB 2.0 OTG |
| HDMI | 1 × lockable |
| Serial | 1 × RS-232 / RS-422 / RS-485 |
| CAN | 1 × CAN 2.0b |
| Optional I/O | 2 × I²C, 2 × SPI, 1 × UART, 8 × GPIO, Relay |
| Expansion | 1 × Mini PCIe; 1 × M.2 B-key 2242 |
| Wireless Support | Wi-Fi / LTE via expansion |
| Storage | 128GB NVMe standard |
| DC Input | 12 VDC |
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions | 148 × 120 × 52 mm |
| Weight | 1.7 kg |
| Mounting | DIN-rail / VESA (optional) |
| WDT | Supported |
Product Features
- Available functions include NVIDIA Jetson Orin NX 16GB and 8GB plus Orin Nano 8GB and 4GB configurations.
- up to 100 TOPS AI performance for real-time inference at the industrial edge is provided by the unit.
- Fanless small enclosure is intended for continuous industrial edge-computing deployment.
- The supplied design incorporates dual Gigabit Ethernet, four USB 3.0 Type-A ports, lockable HDMI, USB 2.0 OTG, serial RS-232/422/485 and CAN 2.0b.
- Supported by Optional expansion: I²C, SPI, UART, eight GPIO and relay interfaces through a 37-pin D-sub connector.
- Supported by Mini PCIe and M.2 B-key expansion: Wi-Fi/LTE connectivity; 128GB NVMe storage is standard.
- Available functions include DIN-rail or optional VESA mounting for industrial automation, robotics and machine-vision installations.
Package Includes
- 1 × AT-09-BXPC-Orin AI Edge Box PC in the selected NVIDIA module configuration
- 128GB NVMe storage (standard configuration)
- AT-09-BXPC-Orin datasheet access
